SPECIFICATIONS
RATING: 50mA/12VDC.
ELECTRICAL LIFE: 200,000 make-and-break cycles at full load
MECHANICAL LIFE: 1,000,000 cycles
INSULATION RESISTANCE: 0?0LQ
DIELECTRIC STRENGTH: 250V RMS@sea level.
CONTACT RESISTANCE:P?0D[ ,QLWLDOYDOXH
OPERATION TEMPERATURE: -20°C~+70°C
TRAVEL: 0.85mm±0.25mm.
OPERATION PRESSURE: 450gf±150gf.
INGRESS PROTECTION: ,3 ,QKRXVHWHVW
TORQUE: 11.5 kgf．cm
MATERIALS
BUSHING: Stanless Steel
BASE: Nylon 6/6.
ACTUATOR: 3& 7UDQVOXFHQW8/ 9
CAP: Stanless Steel
RUBBER: 6LOLFRQH 7UDQVOXFHQW
SEALING: 9LWRQ
O-Ring: 6LOLFRQH 7UDQVOXFHQW
TERMINAL:%UDVV*ROGIODVKRYHUVLOYHUSODWHG
CONTACT:6WDLQOHVV6LOYHUSODWHG
HEX NUT: %UDVV 1LFNHOSODWHG
