产品类型:密封超小型钮子开关
规格参数
额定值:3A120VAC1A250VAC
功率:Dependent upon contact material
机械寿命:30,000 make – and – break cycles.
接触电阻:20mΩ max.Initial @ 2-4VDC,100 mA for both silver and gold plated contacts.
绝缘电阻:1,000MΩmin。
绝缘强度:1,000Vrms min @ sea level.
工作温度范围:-30℃ to 85℃.
材质
外壳&铜头:Glass filled nylon 66, flame retardant,heat stabilized(UL94V-0).
摇杆:Brass,chrome plated, internal O-ring seal. Standard of all actuators.
支撑支架:Brass ,tin plated.
端子/弹片:Copper alloy with Silver or gold plated
