轻触开关_DTS-2

Size:12x12mm
Through Hole Type





SPECIFICATIONS
Operation Force:520±130gf Yellow(Y)
320±80gf Salmon(S)
                             260±50gf Red(R)
                             160±50gf Brown(N)
                             100±50gf Black(K)
Stop Strength: Max 3kgf vertical static load continuously
                      for 15 seconds
Stroke : (12x12) 0.35±0.1mm
              (6x6) 0.25+0.2/-0.1mm
Operation Temperature Range : -25℃ to +70℃
Storage Temperature Range : -30℃ to +80℃
ELECTRICAL (6X6)
Electrical Life300,000 cycles for 320gf,520gf
                        500,000 cycles for 260gf
                       1,000,000 cycles for 100gf,160gf

Rating50mA , 12 VDC

Contact Resistance100m? max
Insulation Resistance100M? min , 500 VDC
Dielectric Strength250 VAC / minute
Contact Arrangement1 pole 1 throw

MATERIAL
COVER : Stainless steel
CONTACT DISC:Phosphor bronze with silver cladding(Standard)
                           Stainless Steel(V-Option)
TERMINALBrass with silver plated
BASE:UL94V-0 Nylon High-Temp. Thermoplastic
STEMUL94V-0 Nylon High-Temp. Thermoplastic
ColorBlack(100gf) , Brown(160gf) , Red(260gf)
           Salmon(320gf) , Yellow(520gf)
(Phosphor bronze)
ELECTRICAL (12X12)
Electrical Life: 100,000 cycles for 320gf
                         100,000 cycles for 260gf
                         200,000 cycles for 160gf
(Stainless Steel)
Electrical Life: 500,000 cycles for 260gf
                       1,000,000 cycles for 160gf
