Circuit: SP5T
Current rating: 50mA@12V DC
Contact resistance: Initial value: maximum 500 milliohms
Insulation resistance: minimum 100 megohms
Operating force: S1~S4 are 400 grams of force ± 150 grams of force, and S5 is 250 grams of force ± 100 grams of force
Total travel: 0.5mm ± 0.3mm
Mechanical lifespan: minimum 200,000 cycles
Operating temperature: -25℃~+60℃
Protection level: IP65
Applications: Automation control consoles, marine instruments, outdoor control equipment
